4K HDR HDMI Compact PoC Extender 4K60 DGKat 2.0 Kit, 229'

  |   Q&A

$420.00

Free shipping on orders over $99

Part #: PT-871/2xr-KIT
Vendor: Kramer
Ships directly from manufacturer
Maximum quantity available reached.

The Kramer PT-871/2XR-KIT is an extender kit containing a transmitter and receiver for providing long reach signals and 2-way power over twisted pair. The transmitter converts the HDMI input signal into a DGKat 2.0 signal, while the receiver converts the transmitted DGKat 2.0 back into an HDMI signal. The PT-871/2XR-KIT extends video signals up to 60m (200ft) at 4K 60Hz (4:4:4) resolution and up to 70m (229ft) at 4K 30Hz (4:4:4) 24bpp resolution over Kramer's shielded cables.

High Performance Extender

The Kramer PT-871/2XR-KIT provides long reach signals and 2-way power over twisted pair copper infrastructures. It employs low-level video compression technology for lossless performance HDR signals 4K at 60Hz (4:4:4) and near-zero latency.

HDMI Signal Extension

HDR, HDMI 2.0 and HDCP 2.2 compliant. The PT-881/2XR-KIT supports deep color, x.v.Color, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0.  EDID pass-through ensures Plug and Play operation for HDMI from source to display.

Easy Installation

The Compact Pico TOOLS fan-less enclosure allows for device-back mounting, or side-by-side mounting of 4 units in a 1U rack space with the recommended rack adapter. The single twisted-pair cable provides cable and signal power wiring for easy installation and use.

Specifications:

Inputs: 1 female HDMI, 1 DGKat on female RJ-45
Outputs: 1 DGKat on female RJ-45, 1 female HDMI
Transmitted data bandwidth: up to 18Gpbs (6Gpbs per graphic channel)
Max resolution at high compression level: 3840x2160@60Hz (4:4:4) 24bpp
Max resolution at standard compression level: 4096x2160@60Hz (4:4:4) 24bpp
HDCP 2.2 and HDR10 compliant
HDMI support Deep color, x.vColor, lip sync, HDMI uncompressed audio channels,
Dolby True HD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0
Standard compression reach extension: using shielded UNIKAT cables up to
130ft at 4K@60Hz (4:4:4), up to 229ft at 4K@30Hz (4:4:4)
or full HD (1080p @60Hz 36bpp)
DGKat 2.0 compliant
Includes: transmitter, receiver, power adapter with cord, 2 bracket sets
Dimensions: 2.45" x 2.04" x 0.96"
Weight:  0.5lbs
7 year warranty
Specifications (PDF)
Quick Start Guide (PDF)
User Manual (PDF)

Kramer SKU: 50-80389390
Inputs: 1 female HDMI, 1 DGKat on female RJ-45
Outputs: 1 DGKat on female RJ-45, 1 female HDMI
Transmitted data bandwidth: up to 18Gpbs (6Gpbs per graphic channel)
Max resolution at high compression level: 3840x2160@60Hz (4:4:4) 24bpp
Max resolution at standard compression level: 4096x2160@60Hz (4:4:4) 24bpp
HDCP 2.2 and HDR10 compliant
HDMI support Deep color, x.vColor, lip sync, HDMI uncompressed audio channels,
Dolby True HD, DTS-HD, 2K, 4K, and 3D as specified in HDMI 2.0
Standard compression reach extension: using shielded UNIKAT cables up to
130ft at 4K@60Hz (4:4:4), up to 229ft at 4K@30Hz (4:4:4)
or full HD (1080p @60Hz 36bpp)
DGKat 2.0 compliant
Includes: transmitter, receiver, power adapter with cord, 2 bracket sets
Dimensions: 2.45" x 2.04" x 0.96"
Weight:  0.5lbs
7 year warranty
Specifications (PDF)
Quick Start Guide (PDF)
User Manual (PDF)
